P10 P16 P20 Indoor Transparent Crystal Film Screen

Product Feature

1. Ultra-thin and ultra-lightFast front and rear maintenance
The thickness of the film screen is 1 - 3mm and the weight is 2 KG/㎡
2. Supports cutting, highly flexible
Can be easily cut to desired size, Can be applied to glass/wall surfaces of any curvature .
3. Cost-saving installation
No steel frame structure or changes to the building's appearance are needed, effectively reducing transportation and installation costs
4. High transparency rate and easy
Transparency Rate up to 95%. It won't affect daily lighting, just lightly stick the film screen and connect the signal and power. It adopts a solution of point-to-point transmission
5. Resume from Breakpoints
The light-emitting chips use a micron-level light source and a four-in-one package method. Besides LED chips there are no other electronic or device components. It adopts a solution of resuming from breakpoints, so that if one point fails, it will not impact the normal display of other chips.

More details

We can help you to design and customize your own led display, we work with professional engineers who continuously develop new products, constantly solve the pain points of the market and industry of led display.

One stop led video wall solutions: We provide complete led video wall proposal, including led panels, power
supply, control system, hanging beam, flight case, installation frame and other accessories.

Knowing that our products and your needs is the most important thing, suitable proposal can save so many times and cost.
24 hours online pre-sale and after-sales customer service, no time difference

Product Size

Product Specification

P10 Indoor Transparent Crystal Film Screen

Pixel pitch	10mm
Led type	SMD2020
Usage	Indoor
Protection class	IP45
Brightness	1500-5000nits/m²
Display Thickness	1-3mm
Led panel size	960x 230/1440 x 230mm
Pixel density	10000 dot/m²
Weight	≤2kgs/m²
Power supply	220V±10% ; AC50HZ
Avg power consumption	240W / m2 – Smart Power system for less consumption
Max power consumption	800W / m2 – Smart Power system for less consumption

P16 Indoor Transparent Crystal Film Screen

Pixel pitch	16mm
Led type	SMD2020
Usage	Indoor
Protection class	IP45
Brightness	1500-4500nits/m²
Display Thickness	1-3mm
Led panel size	960x 224/1440 x 224mm
Pixel density	3906 dot/m²
Weight	≤2kgs/m²
Power supply	220V±10% ; AC50HZ
Avg power consumption	200W / m2 – Smart Power system for less consumption
Max power consumption	600W / m2 – Smart Power system for less consumption

P20 Indoor Transparent Crystal Film Screen

Pixel pitch	20mm
Led type	SMD2020
Usage	Indoor
Protection class	IP45
Brightness	1500-3500nits/m²
Display Thickness	1-3mm
Led panel size	960x 220/1440 x 220mm
Pixel density	2500 dot/m²
Weight	≤2kgs/m²
Power supply	220V±10% ; AC50HZ
Avg power consumption	200W / m2 – Smart Power system for less consumption
Max power consumption	600W / m2 – Smart Power system for less consumption

Technical Specification

Led lifetime	100000 hours
Viewing Distance	Clear image visible at 8m-250m distance
Viewing angle	160 ° / 140 °. Extended angle that improves viewing of images from the side
Working temperature and humidity	Operating environment: -10~+65￮c/ 10~90%RH Storage environment: -40~+85￮c/ 10~90%RH
Refresh rate	≥3840Hz
Control system	Colorlight/Novastar, synchronous/asynchronous
Video signal input	HDMI, DVI, VGA…
Gray level	≥16 bit
Brightness control	Programmable
Power Supply Brand	YUANCHI
Color Temperature	5500K-15000K(adjustable)
Driving Method	Static
Attenuation Rate	Less than 0.05% in 2 years
Frame Rate	≥60HZ
Trouble-Free Operating Time	≥10,000 hours
Led chip Failure Rate	≤1/10,000
Installtion Method	Adhering to glass, Hanging installation, Fixed installation, Support arbitrary size cropping and bending
